1120-4A-RED-1000 - Nylon Air Brake Tubing

Name: 1120-4A-RED-1000 - Nylon Air Brake Tubing
SKU: 1120-4A-RED-1000
Price: 0.92 USD
Availability: InStock

Parflex makes enough air brake tubing a year to circle the globe twice. Brake Line tubing provides excellent kink resistance. This means reduced, and or, eliminated kinked lines resulting in less rework at installation on semi-truck air lines.

Manufacturer: Parker

Availability:

6366 in stock

Kansas City, KS

6,366

Partner Available:

8610 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU 1120-4A-RED-1000

$0.92/foot

Qty:

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	FT	Tube O.D. (inch)	1/4
Standard Pack Qty (ft)	1000	Color	Red
Cover Color	n/a	Weight	0.018 kg/m
Maximum Operating Temperature	93 °C	Size	-4
Division	Parflex Division	Compatible Fitting	PTC
Tube Material	Polyamide (PA)	Media	Air
Tube Inside Diameter	0.17 inch	Color	Red
Minimum Bend Radius	1 inch	Minimum Operating Temperature	-40 °F
Cover Material	n/a	Application	Air Brake
Specifications Met	SAE J844	Tube Outside Diameter	0.25 inch
Minimum Burst Pressure	82.7 bar	Maximum Operating Pressure	10.3 bar
