50AT103BBPGN20H - Low Pressure Spin-On Filters 12AT/50AT Series

Our rebranded Spin-On Low Pressure Filter Series are cost effective yet uncompromising in performance and quality. Max allowable operating pressure of 150 PSI/10.3 Bar and capable of flows up to 50 GPM/190 LPM depending on viscosity.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 28 days
Partner Available:	Backordered

SKU 50AT103BBPGN20H

$167.98/each

Products specifications

Attribute name	Attribute value
UOM	EA	Seal Material	Nitrile
Options	Inlet & Outlet, both sides (all ports drilled & tapped)	Indicator Type	Sold separately
Bypass Valve (psi)	25	Filter Element	3 micron microglass
Flow Rate (gpm)	36	Port Connection Type	1-1/4" NPT ports
For Fluid Type	Suitable for use with mineral and vegetable oils, and some synthetic oils. For other fluids, please e-mail Technical Support at HFF.technical@support.parker.com or call 800-253-1258.	Maximum Operating Temperature	225
Division	Engine Mobile Hydraulic and Fuel Filtration Division	Bypass Valve Pressure Rating	25
Options	Inlet & Outlet, both sides (all ports drilled & tapped)	Seal Material	Nitrile
Housing Material	Low Carbon Steel	Indicator Type	Sold separately
Compatible Element	934200	Flow Rate	36
Mounting Type	Inline	Port Type	1-1/4" NPT ports
Weight	3.9	Indicator Pressure Setting	20
Pressure Rating	10.3	Filter Element Type	Canister
