| UOM | EA | Seal Material | Fluorocarbon |
| Maximum Inlet Pressure Rating | 5000 PSI, 350 BAR | Configuration | Floating Center |
| Override Functionality | Non-Detented | Flow Rate | 2.7, 4 GAL/MIN, 10, 15 L/MIN |
| Coil Type | 1/2" Super Coil | Leak Rate | 10 @ 3000 PSI (210 BAR) cm3/min |
| Maximum Operating Temperature | +400 °F | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Hysteresis | Less than 6% | Frequency | 100-400 Hz |
| Valve Material | All parts steel. All operating parts hardened steel | Maximum Flow Rate | 10, 15 L/min |
| Maximum Tank Pressure | 3000 psi | Maximum Inlet Pressure Rating | 5000 psi |
| Function | Proportional Directional Control | Seal Material | Fluorocarbon |
| Response Time | 50 ms | Power Consumption | 14, 19 W |
| Cavity Size | C08-4 | Minimum Operating Temperature | -26 °C |
| Current | 1.15 @ 12 VDC, 1.58 @ 12 VDC, 0.58 @ 24 VDC, 0.79 @ 24 VDC A | Override Functionality | Non-Detented |
| Flow Rate | 2.7, 4 Gal/min | Variation of Opening Point | 25% - 30% of Input Signal |
| Actuation Type | Electrical, Manual | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Operating Temperature | -26 to +204 °C |
| Maximum Operating Pressure | 350 bar | Configuration | Floating Center |
| Coil Nut Tightening Torque | 3 lb-ft | Body Material | N/A |
| Division | Hydraulic Systems Division | Operation Type | Solenoid operated, Manually operated |
| Flow Rate Accuracy | +/- 15% @ 75% Nominal Current and Constant DeltaP Maintained with Pressure Compensator | Weight | 0.15 kg |
| Installation Torque | 30 Nm | | |
