95U-2-031-0100 - PU Tubing

Flexible Polyurethane Tubing -95U/95UM Series offers the greatest flexibility and kink resistance along with exceptional abrasion resistance of any rubber or thermoplastic tubing.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 14 days
Partner Available:	268 in stock

SKU 95U-2-031-0100

$0.56/foot

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	FT	Standard Pack Qty (ft)	100
Product Type	Inch	Color	Natural
Order Size	1/8	Maximum Operating Pressure	17.2 bar
Minimum Operating Temperature	-40 °F	Tube Outside Diameter	1/8 inch
Application	Machine Tools	Minimum Burst Pressure	750 psi
Tube Material	Polyurethane	Tube Inside Diameter	0.063 inch
Media	Water	Compatible Fitting	TrueSeal™
Maximum Operating Temperature	180 °F	Division	Parflex Division
Material	Polyurethane	Max. Operating Pressure	17.2 Bar 250 psi
Min. Operating Temperature	-40 °F -40 °C	Min. Burst Pressure	750 psi 51.6 Bar
Inside Diameter	0.063 Inch 1.6 MM	Wall Thickness	0.031 Inch 0.8 MM
Outside Diameter	1/8 Inch 3.2 MM	Max. Operating Temperature	180 °F 82 °C
Media	Air, Water	Parker Division	Tubing
Parker Group	Fluid Connector
