| UOM | EA | Override Functionality | N/A |
| Maximum Inlet Pressure Rating | 5000 PSI, 350 BAR | Seal Material | D-Ring (Standard) |
| Configuration | Pressure Reducing/Relieving | Maximum Flow Rate | 10 GAL/MIN, 37.5 L/MIN |
| Wire Mesh Screen Included | N/A | Maximum Regulating Pressure | 300 PSI, 21 BAR |
| Flow Direction | Inlet port 1, Reducing port 2, Tank port 3 | Wire Mesh Screen Included | N/A |
| Response Time | N/A ms | Current | 0.9 at 12VDC, 0.45 at 24VDC A |
| Power Consumption | 9 @ Max Reduced Pressure W | Cavity Size | C10-3L |
| Minimum Operating Temperature | -37 °C | Override Functionality | N/A |
| Leak Rate | 492 @ 300 PSI (21 BAR), 946 @ 3000 PSI (210 BAR) cm3/min | Hysteresis | 4% |
| Maximum Operating Temperature | +93 °C | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Frequency | 200-600 Hz | Valve Material | All parts steel. All operating parts hardened steel |
| Division | Hydraulic Cartridge Systems Division | Maximum Pressure Setting | N/A psi |
| Maximum Flow Rate | 10 Gal/min | Maximum Inlet Pressure Rating | 350 bar |
| Function | Proportional Pressure Reducing | Maximum Tank Pressure | N/A psi |
| Seal Material | D-Ring (Standard) | Division | Hydraulic Systems Division |
| Body Material | N/A | Operation Type | Solenoid operated |
| Installation Torque | 50-56 Nm | Weight | 1.3 lb |
| Maximum Regulating Pressure | 21 bar | Coil Type | 1/2" Super Coil Low Watt (CCS) |
| Maximum Drain Flow Rate | N/A cm3/min | Mounting Type | Screw in cartridge valve |
| Flow Rate | 37.5 L/min | Operating Temperature | -35 to +200 °F |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Actuation Type | Electrical |
| Configuration | Pressure Reducing/Relieving | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Coil Nut Tightening Torque | 7-9.5 Nm | Maximum Operating Pressure | 5000 psi |
