309P-4-2N - Plastic Barbed Fittings, Parker Par-Barbs

Parker's Par-Barb fttings are specially engineered with a four-barb design that generates maximum gripping and sealing power when combined with a hose clamp.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 25 days
Partner Available:	Backordered

SKU 309P-4-2N

Products specifications

Attribute name	Attribute value
UOM	EA	Color	White
Product Style	Female Pipe to Male Pipe	Connection 1 Size	1/4"
Connection 1 Type	Male Pipe	Connection 2 Size	1/8"
Connection 2 Type	Female Pipe	Connection 2 Thread Size	1/8"
Connection 2 Hose I.D. (inch)	n/a	Shape	Reducer Bushing
Body Material	Nylon,White	Configuration	Pipe to Pipe
Connection 3 Size	N/A	Connection 3 Type	N/A
Connection 1 Thread Size	1/4"	Connection 1 Hose I.D. (inch)	n/a
Application	Beverage Dispensing	Brand	Parker
Specifications Met	FDA	Dimensional Weight	0.5755 lb
Configuration	Pipe to Pipe	Media	Water
Technology	Fluid & Gas Handling	Connection 3 Size	N/A
Connection 2 Type	Female NPT	Connection 1 Size	1/4
Minimum Operating Temperature	-40 °F	Color	White
Connection 3 Type	N/A	For Fluid Type	Water
Division	Fluid System Connectors Division	Connection 2 Size	1/8
Maximum Operating Temperature	93 °C	Compatible Tube	Vinyl
Body Material	Nylon	Vacuum Pressure Rating	-29
Shape	Reducer Bushing	Connection 1 Type	Male NPT
Maximum Operating Pressure	8.5 bar	Division	Fluid System Connectors Division
