NNR-6-048 - Nylon Tubing - NR Series

Name: NNR-6-048 - Nylon Tubing - NR Series
SKU: NNR-6-048
Price: 2.02 USD
Availability: InStock

High Strength Nylon Tubes - NR Series Polyamide Tubing features low moisture absorption and better chemical resistance than Series N Nylon Tubing.

Availability:

247 in stock

Olivette, MO	167
TOPEKA, KS	80

Partner Available:

374 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU NNR-6-048

$2.02/foot

Qty:

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	FT	Order Size	3/8
Standard Pack Qty (ft)	250	Color	Natural
Cover Color	n/a	Maximum Operating Pressure	425 psi
Weight	0.022 lb/ft	Maximum Operating Temperature	93 °C
Compatible Fitting	Prestolok®	Size	-6
Length per Package	250 ft	Division	Parflex Division
Minimum Bend Radius	1.75 inch	Minimum Operating Temperature	-51 °C
Cover Material	n/a	Tube Inside Diameter	0.279 inch
Media	Air	Tube Material	Polyamide (PA)
Application	Pneumatics	Tube Outside Diameter	9.5 mm
Specifications Met	n/a	Minimum Burst Pressure	117.2 bar
Outer Diameter 1	3/8 Inch	Max Pressure	425 PSI (30 bar)
Inner Diameter	0.279 Inch	Pkg Qty	250
Color	Natural	Pkg Qty/UOM	250 FT
UOM	FT	Wall Thickness	0.048 Inch
Material	Nylon	Outer Diameter	3/8 Inch
Inner Diameter	0.279 Inch	Trade Name	Parflex
Wall Thickness	0.048 Inch	Series	N
Material	Nylon	Color	Natural
Distinct Properties	Chemical Resistant	Max Pressure Range	250 to 499 PSI (17 to 34 bar)
Parker Division	Parflex	Application	Pneumatic
Wall Thickness Inch/mm	Inch	Inner Diameter Inch/mm	Inch
Parker Group	Fluid Connector	Outer Diameter Inch/mm	Inch
Inch/Metric	Inch
