7181-251 - Heavy Duty Heater Hose, Series 7181

Heavy Duty Heater Hose is designed for use in heater and radiator systems in vehicles and industrial equipment in applications to 257°F and 65 psi, Series 7181

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 12 days
Partner Available:	1581 in stock

SKU 7181-251

$1.61/foot

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	FT	Hose I.D. (inch)	1/4
Maximum Working Pressure (psi)	65	Standard Pack Qty (ft)	700
Division	Hose Products Division	Application	Specialty
Media	Coolants	Maximum Operating Pressure	4.5 bar
Maximum Operating Temperature	257 °F	Minimum Operating Temperature	-40 °C
Specifications Met	SAE J20R3EC, Class D2	Weight	0.10 lb/ft
Outside Diameter	0.530 inch	Cover Material	Ethylene Propylene Diene Monomer (EPDM)
Inside Diameter	1/4 inch	Compatible Fitting	n/a
Minimum Bend Radius	63.5 mm	Hose Inner Tube Material	Black
Hose Reinforcement Material	2 Plies of Textile	Cover Color	Black
Package Type	Reel
