490R30 - Fuel Filter Water Separator – Racor Spin-on Series

Racor Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. Integral priming pump and fuel heater available as an option.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 106 days
Partner Available:	Backordered

SKU 490R30

$390.91/each

Products specifications

Attribute name	Attribute value
UOM	EA	Location	North America and EMEA regions
Micron Rating	98% @ 30 Micron	Mounting	Bracket Included
Bowl Type	Standard, Clear Engineering Plastic	Part Type	Filter Assembly
Bowl Material	Clear Engineering Plastic	Heater Power Rating	No Heater
Port Size	3/8"-18 NPTF (SAE J476)	Product Series	Diesel Spin-on 400
Integral Primer Pump Included	Button Priming Pump (Diesel)	Flow Rate	90 gph (341 lph)
Division	Engine Mobile Original Equipment Division	Filter Element Type	30 Micron Aquabloc Spin-on
Width	114.0 mm	For Fluid Type	Diesel
Accessories Included	See Product Support Tab	Height	300.0 mm
Number of Ports	2 Inlet / 2 Outlet	Product Type	Diesel Spin-on FF/WS
Head Material	Aluminium Alloy	Compatible Element	R90S = "2" Micron<br/>R90T = 10 Micron<br/>R90P = 30 Micron
Brand	Racor	Maximum Fluid Temperature	88.0 °C
Operating Temperature	-40 to 121 °C	Depth	4.8 inch
Maximum Operating Pressure	207.0 kPa	Weight	1.4 kg
Clean Pressure Drop	6.5 kPa

Product resources

Literature and Reference Materials

Selector Guides

Racor--400 Diesel Spin-on--RSL0366 (PDF)
