*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

244IFHD-3 - Brass Inverted Flare Fittings

Parker's economical inverted flare fittings offer a metal-to-metal seal that is internal to the fitting for tighter tube bends. Meets functional requirements of SAE J512

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 8 days
Partner Available:	104 in stock

SKU 244IFHD-3

$13.68/each

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Shape	Tee
Connection 2 Thread Size (inch)	na	Connection 1 Tube O.D. (inch)	3/16
Connection 2 Tube O.D. (inch)	3/16	Connection 1 Style	Inverted Flare
Connection 2 Style	Inverted Flare	Style	Flare to Flare
Minimum Operating Temperature	-53 °C	Division	Fluid System Connectors Division
Maximum Operating Temperature	250 °F	Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon
Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared	Nut Material	Brass, Zinc Chromate Steel
Body Material	Brass	Specifications Met	SAE J512
Application	Pumps, Brake Lines	Maximum Operating Pressure	1900 psi
