| UOM | EA | Seal Material | Nitrile |
| Flow Rate | 16 GAL/MIN, 60 L/MIN | Actuation Type | Electrical, Manual |
| Configuration | Normally Closed, Pressure Compensated | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Coil Type | 5/8" Super Coil | Frequency | 100-400 Hz |
| Maximum Flow Rate | 60 L/min | Connection Type | N/A |
| Maximum Regulated Flow Rate | 26, 30 L/min | Division | Hydraulic Systems Division |
| Installation Torque | 22 lb-ft | Operation Type | Solenoid operated, Manually opertated |
| Flow Direction | Inlet port 3, Bypass port 2, Regulated port 4 | Connection Size | N/A |
| Function | Proportional Flow Control/Regulator | Hysteresis | 7% |
| Minimum Pressure Differential | 200, 300 psi | Maximum Operating Temperature | +250 °F |
| Valve Material | All parts steel. All operating parts hardened steel | Seal Material | Nitrile |
| Leak Rate | 780 @ 3000 PSI (210 BAR) cm3/min | Maximum Inlet Pressure Rating | 3000 psi |
| Override Functionality | Infinite Control | Minimum Operating Temperature | -34 °C |
| Power Consumption | 18, 28 W | Current | 1.50 @ 12 VDC, 2.33 @ 12 VDC, 0.75 @ 24 VDC, 1.17 @ 24 VDC A |
| Cavity Size | 4C | Actuation Type | Electrical, Manual |
| Body Material | N/A | Flow Rate Accuracy | +/- 20% of Input Signal |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Coil Nut Tightening Torque | 4.1 Nm |
| Weight | 0.14 kg | Maximum Operating Pressure | 210 bar |
| Operating Temperature | -34 to +121 °C | Variation of Opening Point | 17% Nominal Amperage, 21% Nominal Amperage |
| Flow Rate | 60 L/min | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Configuration | Normally Closed, Pressure Compensated | | |
