| UOM | EA | Seal Material | Nitrile |
| Actuation Type | Electrical | Flow Rate | 8, 9.5 GAL/MIN, 30, 36 L/MIN |
| Configuration | Normally Closed, Partially Pressure Compensated | Connection Size | N/A |
| Variation of Closing Point | N/A | Flow Direction | Bi-directional |
| Function | Proportional Flow Control/Regulator | Wire Mesh Screen Included | No |
| Maximum Operating Temperature | +250 °F | Minimum Pressure Differential | N/A psi |
| Leak Rate | 378 @ 3000 PSI (210 BAR) cm3/min | Maximum Inlet Pressure Rating | 210 bar |
| Hysteresis | < 10% | Seal Material | Nitrile |
| Valve Material | All parts steel. All operating parts hardened steel | Minimum Operating Temperature | -34 °C |
| Override Functionality | N/A | Power Consumption | 18, 28 W |
| Current | Max: 1.50 @ 12 VDC, 2.33 @ 12 VDC, 0.75 @ 24 VDC, 1.17 @ 24 VDC A | Cavity Size | C10-2 |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Flow Rate Accuracy | +/- 2% |
| Actuation Type | Electrical | Body Material | N/A |
| Weight | 0.12 kg | Maximum Operating Pressure | 210 bar |
| Coil Nut Tightening Torque | 4.1 Nm | Flow Rate | 8, 9.5 Gal/min |
| Configuration | Normally Closed, Partially Pressure Compensated | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Operating Temperature | -30 to +250 °F | Variation of Opening Point | 17% of Input Signal, 21% of Input Signal |
| Division | Hydraulic Cartridge Systems Division | Frequency | 100-400 Hz |
| Coil Type | 5/8" Super Coil | Maximum Flow Rate | 8, 9.5 Gal/min |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Connection Type | N/A |
| Operation Type | Solenoid operated | Division | Hydraulic Systems Division |
| Installation Torque | 22 lb-ft | | |
